HPE Aruba CX 9300 Series 9300-32D 32-Port 100/200/400GbE QSFP-DD Ethernet Switch - Next-Generation High-Density Data Center Network Switch with 25.6Tbps Performance and Flexible Breakout Capabilities for Enterprise Server Storage Infrastructure

About the Product

The HPE Aruba CX 9300-32D represents the next generation of data center switching technology. This high-performance 1U fixed configuration switch delivers 25.6Tbps of switching capacity with 32 ports of 100/200/400GbE connectivity via QSFP-DD interfaces. Designed for modern data center environments, the 9300-32D provides flexible, cost-effective, high-density networking for servers, storage, and intra-fabric connectivity. The switch supports large data center pods of up to 6,000 x 25GbE servers or 2,000 x 100GbE servers, representing an 8x jump in scaling density over previous generation switches. With flexible breakout capabilities, each 400Gbps port can be configured as 4x100GbE, 2x200GbE, or 1x400GbE to match specific connectivity requirements.

Tech Specs

Form Factor: 1U rackmount fixed configuration • Switching Capacity: 25.6Tbps bidirectional • Forwarding Rate: 5Bpps wire-speed • Data Ports: 32x QSFP-DD 100/200/400GbE ports • Management Ports: 2x 10GbE SFP+ ports • Power Consumption: 210W typical • Cooling: 6 cooling fans with front-to-back or back-to-front airflow options • Power Supplies: Dual redundant AC PSU bundle • Operating System: AOS-CX with REST APIs and Python scripting • Supported Standards: QSFP-DD MSA (400G), QSFP56 (200G), QSFP28 (100G), QSFP+ (40G) • Breakout Support: Flexible port breakout with QSA28 adapter support for 25G and 10G • TAA Compliant: Yes
