HPE Aruba Networking 9100 Series 9106 Hybrid Gateway Router - Cloud-Optimized Edge Appliance for Branch & Campus Networks with 2x SFP+ 2x Combo 2x PoE - Scalable High-Performance SD-WAN Security Gateway Supporting up to 4K Access Points

About the Product

The HPE Aruba Networking 9106 from the 9100 Series is a cloud-optimized hybrid gateway designed to securely extend enterprise services to medium branch, large branch, and small campus networks. This versatile edge appliance combines scalable high-performance Wi-Fi capabilities with intelligent routing and automated policy enforcement. Supporting up to 4K access points and 10K clients, the 9106 delivers seamless roaming, 24/7 reliability, and always-on connectivity even during upgrades. With advanced wireless capabilities, SD-WAN functionality, and VPN concentrator features, it serves as a comprehensive networking solution managed through HPE Aruba Networking Central for unified cloud-based operations.

Tech Specs

Ports: 2x SFP+ 10G fiber ports, 2x Combo 1G SFP ports, 2x GbE ports with 60W PoE budget; Management: 1x RJ45 out-of-band management port, USB-C and RJ45 console ports, USB 3.0 type-A; Performance: Up to 20 Gbps throughput, supports up to 4K access points and 10K clients, 1,000 concurrent IPSec tunnels, 8,000 IPv6 neighbor table entries; Physical: 1U rackmount form factor, dimensions 43.7mm H x 294.8mm W x 201.05mm D, weight 2.305 kg; Power: 100-240 VAC input, 54V output, operating temperature 0-40°C; Software: AOS-10 or AOS-8 support, managed via Aruba Central; Certifications: CSA/UL 62368-1, FCC Part 15 Class B, EN55032 Class B
